2p Surge Protective Device

The Zhechi Electric® 2p Surge Protective Device in stock protect against lightning surge voltages in solar system (photovoltaic power supply system).

Send Inquiry

Product Description

Cheap 2p Surge Protective Device In Stock with 2 Years Warranty

Description of The Zhechi Electric® 2p Surge Protective Device :

These units must be installed in parallel on the DC networks to be protected and provide common and different modes protection. Its installed location are recommended at both ends of the DC power supply line (solar panel side and inverter/converter side), especially if the line routing is external and long.

High energy MOVs equipped with specific thermal disconnectors and related failure indicators.

Features of The Zhechi Electric® 2p Surge Protective Device

1. Indicator window is obvious (green is OK, red indicates failure)

2. Fully enclosed terminal

3. The shell is made of PC flame retardant material, fire insulation

4. Replaceable module

Technical Data of DC 1000v Surge Protective Device

Item 2p Surge Protective Device
Code ZC-D40
Pole 2P 3P
Voltage 12VDC- 600VDC 12VDC- 1000VDC
In(8/20)us(KA) 20KA
Imax(8/20)us(KA) 40KA
Standard IEC/EN61643
Type II
Characteristic Curve B,C,D
Working Temperature "-5°"to +40°
Protection Degree IP20
Electrical life More than 8000times
Mechanical life More than 2000times
Dimension(W)X(H)X(D) 36x90x68 54x90x68
Installation 35MM DIN RAIL
Accessory Remote signal
Installation Altitude ≤2000M
