1000vDC MCCB
  • 1000vDC MCCB1000vDC MCCB

1000vDC MCCB

The latest selling Zhechi Electric®1000vDC MCCB in stock with thermo-magnetic overload and short circuit release are used for photovoltaic installation from array combiner boxes to AC/DC inverter and main panel with excellent rating for both AC and DC applications.Also a complete range of accessories are provided upon request,such as shunt release, under-voltage release, auxiliary switch and alarm switch.

Send Inquiry

Product Description

China Latest Selling The Zhechi Electric® 1000vDC MCCB In Stock

1000v DC MCCB with thermo-magnetic overload and short circuit release are used for photovoltaic installation from array combiner boxes to AC/DC inverter and main panel with excellent rating for both AC and DC applications.Also a complete range of accessories are provided upon request,such as shunt release, under-voltage release, auxiliary switch and alarm switch.

Features of 1000v DC MCCB
Conform to IEC 60947-2 standards
Compact design
High breaking capacity
Thermo-magnetic trip
2,3&4 pole are available
Various accessories are available
Technical Data of 1000v DC MCCB

Model
ZC-125MPV ZC-250MPV ZC-400MPV ZC-800MPV
Rated current(A) 63,80,100,125 125,160,200,225,250 250,315,350,400 500,630,700,800
Rated operating voltage(V DC) 1000
Rated Impluse withstand voltage Uimp(V) 8000
Ultimate breaking capacity Icu(A) 15000
Mechanical endurance 4000
Electrical endurance 100
Standard IEC 60947-2/GB 14048-2 UL489
